MOLEX 5025850670 PCB Connector
The 5025850670 is a 1.50mm pitch CLIK-Mate wire-to-board PCB receptacle designed for signal applications. Featuring a single row, right-angle orientation, and tin-plated copper alloy metal contacts, it provides reliable connections with up to 6 circuits. Suitable for surface-mount technology, it offers a maximum current of 2.0A per contact and withstands operating temperatures from -40°C to +105°C. Its durable design includes a mating cycle life of up to 30 cycles and complies with RoHS standards, making it ideal for compact electronic assemblies.
MOLEX 5025850670 PCB Connector Specifications:
- Pitch: 1.50mm
- Voltage Rating: 100V
- Current per Contact: 2.0A
- Operating Temperature Range: -40°C to +105°C
- Material: Copper Alloy
- Plating: Tin
- Color: Beige
- Durability: Up to 30 mating cycles
- Orientation: Right Angle
- Number of Circuits: 6
- Mated Height: 6.40mm
- Locking Features: Guide, Keying, Lock to Mating Part
- Termination: Surface Mount
- Packaging: Embossed Tape on Reel
- UL Certification: E29179
- Compliance: RoHS, China RoHS
- Glow-Wire Capable: No
- Flammability: SC-0
- Stackable: No
- Mates With: 502578 Crimp Housing
Buy the Molex 5025850670 – Reliable Signal Connector for Industrial Applications
Enhance your electronic assemblies with the Molex 5025850670 PCB connector. Designed with a 1.50mm pitch, it offers robust right-angle surface mount connections suitable for signal applications. Built from durable copper alloy with tin plating, it supports up to 6 circuits and withstands operation from -40°C to +105°C. Certified to RoHS standards, this connector provides reliable mating cycles and electrical performance, ideal for compact, high-quality industrial and electronic projects. Order online now for fast delivery and guaranteed quality.
Order your Molex 5025850670 Series PCB Receptacle today and ensure dependable connections in your electronic projects with this robust and compact wire-to-board solution.
