MOLEX 5055750771 Wire-to-Board Connector
The Micro-Lock PLUS Vertical Header is a 2.00mm pitch, single-row wire-to-board connector designed for signal applications. Made with durable brass and polyamide resin, it features matte tin plating on both mating and termination surfaces for reliable connectivity. Rated for up to 30 mating cycles, it supports a maximum operating temperature of -40°C to +105°C. This connector provides PCB retention, polarization to both PCB and mating part, and maximum current capacity of 3.0A per contact at 250V. It is ideal for compact electronic assemblies requiring secure, high-quality connections.
MOLEX 5055750771 Wire-to-Board Connector Specifications:
- Pitch: 2.00mm
- Number of Circuits: 7
- Color: Black
- Material - Metal: Brass
- Material - Resin: Polyamide
- Plating - Mating & Termination: Matte Tin
- Durability (Mating Cycles): 30
- Operating Temperature Range: -40°C to +105°C
- Maximum Voltage: 250V AC/DC
- Maximum Current per Contact: 3.0A
- Locking System: Lock to Mating Part
- Orientation: Vertical
- PCB Retention: Yes
- Packaged Type: Embossed Tape on Reel
- Electrical: Surface Mount Termination
- Guided for secure mating, stackable design not supported
Buy the Buy Molex Micro-Lock PLUS Part Number 5055750771 Online
Enhance your electronic projects with the Molex Micro-Lock PLUS Wire-to-Board Connector, featuring a 2.00mm pitch, 7 circuits, and robust matte tin plating. Crafted from brass and polyamide resin, it offers excellent durability through 30 mating cycles, with an operating temperature range of -40°C to +105°C for reliable performance in various environments. Suitable for signal applications, it provides secure PCB retention, polarization for simpler assembly, and supports a maximum voltage of 250V and current of 3.0A per contact, ensuring safety and efficiency.
Get Molex Micro-Lock PLUS 5055750771 today—designed for secure connection reliability, high durability, and high-performance electronic assemblies.
