MOLEX 513534000 Wire-to-Board Receptacle
The MicroClasp Wire-to-Board Receptacle Housing provides a reliable connection solution with a 2.00mm pitch, dual row configuration, and 40 circuits. Made from UL-rated nylon resin, it features a positive lock, is RoHS compliant, halogen-free, and operates within -25°C to +85°C. Designed for easy mating with compatible headers and terminals, it ensures secure, durable electrical connections for various electronic applications in a compact form factor. Suitable for signal and low-power connections, it complies with safety and environmental standards.
MOLEX 513534000 Wire-to-Board Receptacle Specifications:
- Circuits: 40
- Color - Resin: White
- Flammability: 94V-0
- Material - Resin: Nylon
- Temperature Range - Operating: -25°C to +85°C
- Pitch - Mating Interface: 2.00mm
- Gender: Receptacle
- Stackable: No
- Number of Rows: 2
- Packaging Type: Bag
- Certifications: UL
- Glow-Wire Capable: No
- Lock to Mating Part: Yes
- Net Weight: 1714.000 mg
Buy the Molex Series MicroClasp Wire-to-Board Receptacle Housing 0513534000
Order the Molex 0513534000 MicroClasp Wire-to-Board Receptacle today for a durable, reliable, and environmentally friendly connection solution. This dual row, 40-circuit receptacle features a 2.00mm pitch and positive lock for secure mating with compatible headers and terminals. Made from UL-rated nylon, it is halogen-free, RoHS compliant, and operational from -25°C to +85°C. Ideal for signal applications in electronic devices requiring compact, high-quality connections. Purchase online now for fast, trusted delivery and seamless integration into your projects.
Get Molex 0513534000 today—built for reliable and secure wire-to-board connections in electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 513534000?
You can click on the BUY or RFQ button to purchase 513534000 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 513534000?
You can download the 513534000 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 513534000?
MOLEX
