MOLEX 522710679 FFC-FPC Connector
This is a 1.00mm pitch Easy-On FFC/FPC connector with a right-angle, surface-mount design featuring a ZIF bottom contact style, 6 circuits, and high barrier packaging. Designed for reliable connection in electronic applications, it is RoHS compliant, UL and CSA certified, with a maximum operating temperature of +85°C. Made of phosphor bronze with tin-bismuth plating, it is suitable for SMT mounting, offering durability up to 30 mating cycles. The connector is ideal for flexible flat cables and circuit boards requiring a compact, secure connection.
MOLEX 522710679 FFC-FPC Connector Specifications:
- Pitch - Mating Interface: 1.00mm
- Orientation: Right Angle
- Contact Style: ZIF, Bottom
- Circuits: 6
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin-Bismuth
- Material - Plating Termination: Tin-Bismuth
- Material - Resin: Nylon
- Flammability: 94V-0
- Durability (mating cycles max): 30
- Temperature Range - Operating: -40°C to +85°C
- Maximum Current per Contact: 0.5A
- Maximum Voltage: 50V AC/DC
- Packaged as Embossed Tape on Reel
- PCB Mountable: Yes
- Color - Resin: Natural
- Net Weight: 100 mg
- Certification: UL, CSA
- RoHS Compliance: Yes
- Application: Flexible Flat Cables, Circuit Boards
- Width: Suitable for SMT surface mount technology
Buy the Molex Series 52271 FFC-FPC Connector: 0522710679
Purchase the Molex Series 52271 FFC-FPC connector online today for dependable and secure connections in your electronic assemblies. Designed with a 1.00mm pitch, it features a ZIF, right-angle SMT design with 6 circuits and high barrier packaging. Made of durable phosphor bronze with tin-bismuth plating, the connector is RoHS compliant, UL and CSA certified, and supports up to 30 mating cycles. Ideal for flexible flat cables and circuit board applications, it ensures optimal performance in compact electronic designs and is easy to incorporate into your manufacturing process.
Order your Molex Series 52271 FFC-FPC connector today and ensure reliable, compact connections for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 522710679?
You can click on the BUY or RFQ button to purchase 522710679 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 522710679?
You can download the 522710679 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 522710679?
MOLEX
