MOLEX 525592633 FFC/FPC Connector
This Easy-On™ Type FFC/FPC connector features a vertical, surface mount ZIF design with 26 circuits, ideal for flexible flat cables in electronic devices. It includes tape packaging with center placement holes for easy assembly, durable for multiple mating cycles, and operates within a temperature range of -40°C to +85°C. Constructed with phosphor bronze contacts and silver, tin-bismuth plating, it ensures reliable electrical performance with a maximum current of 0.5A and voltage of 50V. Suitable for compact, high-density applications needing secure, space-efficient connections in electronic assemblies.
MOLEX 525592633 FFC/FPC Connector Specifications:
- Circuits: 26
- Color - Resin: Natural
- Entry Angle: Vertical
- Flammability: UL 94V-0
- Mated Height: 3.90mm
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Silver, Tin-Bismuth
- Material - Plating Termination: Silver, Tin-Bismuth
- Material - Resin: Nylon
- Net Weight: 332.508 mg
- Number of Rows: 1
- Orientation: Vertical
- PC Tail Length: 2.00mm
- Temperature Range - Operating: -40°C to +85°C
- Termination Interface: Style: Surface Mount
- Quote for Maximum Current per Contact: 0.5A
- Voltage - Maximum: 50V
- Packaging Type: Embossed Tape on Reel
- Pitch - Mating Interface: 0.50mm
- Pitch - Termination Interface: 0.50mm
- Polarized to PCB: Yes
Buy the Molex Series Easy-On FFC/FPC Connector: 0525592633
Purchase the Molex Easy-On FFC/FPC connector online now to ensure a secure, reliable connection for your electronic assembly. Designed for high-density applications, it features a ZIF, surface mount design with 26 circuits for flexible flat cables. Its durable construction supports numerous mating cycles and operates within -40°C to +85°C. The connector includes tape packaging for easy handling, with a 0.50mm pitch, making it ideal for compact, space-saving electronic devices. Order today for quick delivery and professional quality assurance.
Get Molex 0525592633 today—built for reliable electrical connections with high-density, space-efficient design in electronics.
Frequently Asked Questions
Where can I buy MOLEX 525592633?
You can click on the BUY or RFQ button to purchase 525592633 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 525592633?
You can download the 525592633 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 525592633?
MOLEX
