MOLEX 444320602 Micro-Fit Connector
The Micro-Fit 3.0 Connector System features dual-row, surface-mount compatibility with a PCB, polarized peg, and kinked tails. Designed for board-to-board and wire-to-board applications, it supports 6 circuits with gold selective plating for enhanced durability. Its high-temperature thermoplastic material and UL and CSA certifications ensure reliable performance in various industrial and electronic applications. The connector offers a maximum current of 8.5A per contact and a maximum voltage of 250V AC/DC, making it suitable for power and signal connections requiring secure, long-lasting contacts.
MOLEX 444320602 Micro-Fit Connector Specifications:
- Number of Circuits: 6
- Maximum Circuits: 6
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Flammability: 94V-0
- Durability (mating cycles max): 30
- Temperature Range - Operating: -40°C to +105°C
- PCB Thickness - Recommended: 1.60mm
- PCB Tail Length: 3.30mm
- Pitch - Mating Interface: 3.00mm
- Current Max per Contact: 8.5A
- Voltage Max: 250V AC/DC
- Material - Resin: High Temperature Thermoplastic
- Surface Mount Compatible: Yes
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- RoHS & Recyclable: Compliant
- Process Temperature max: 260°C
- Terminals: Solder type, high temperature
- Maximum Cycles at Max Temp: 001
Buy the Buy Molex Micro-Fit 3.0 Part Number 444320602 Online
Secure your electronic projects with the Molex Micro-Fit Connector designed for high performance and durability. Featuring a vertical, dual-row construction with 6 circuits, gold plating, and surface mount compatibility, this connector is ideal for power and signal applications. It supports up to 8.5A per contact at 250V, providing excellent reliability in demanding environments. Made from high-temperature thermoplastic, it ensures long-lasting performance, meets industry standards, and is RoHS compliant. Purchase online today for seamless integration in your industrial or electronic designs.
Order your Molex Series Micro-Fit 3.0 444320602 connector today and ensure your projects benefit from high current capacity and reliable surface mount connections.
