MOLEX 526100733 FFC-FPC Connector
The Molex Easy-On FFC-FPC Connector features a 1.00mm pitch, vertical slider series with 7 circuits, tin-silver-bismuth plating, and a height of 5.75mm. Designed for surface-mount technology, it offers reliable electrical connection with a maximum current of 1.0A per contact and operates within a temperature range of -40°C to +85°C. The connector is RoHS, REACH, and halogen-free compliant, with a durability of 30 mating cycles. Suitable for compact electronic devices, it ensures secure mating and easy installation in high-density PCB applications.
MOLEX 526100733 FFC-FPC Connector Specifications:
- Pitch: 1.00mm
- Number of Circuits: 7
- Height: 5.75mm
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin-Silver-Bismuth
- Material - Plating Termination: Tin-Silver-Bismuth
- Color - Resin: Natural
- Durability: 30 mating cycles
- Maximum Voltage: 125V
- Current - Maximum per Contact: 1.0A
- Operating Temperature Range: -40°C to +85°C
- Flammability Rating: UL 94V-0
- Packaging: Embossed Tape on Reel
- Actuator Type: Slider
- PCB Mounting: Surface Mount
- PCB Mounting Type: None
- Resistance to Flammability: UL 94V-0
Buy the Buy Molex FFC-FPC Connector Part Number 526100733 Online
Discover the Molex FFC-FPC Connector with a 1.00mm pitch, 7 circuits, and vertical slider for compact, high-density electronic assemblies. Featuring RoHS and halogen-free compliance, it offers excellent durability with 30 mating cycles and a maximum current of 1.0A per contact. Its operating temperature range of -40°C to +85°C makes it suitable for a variety of device applications, ensuring reliable electrical connections and easy installation in surface-mount technology for modern electronics.
Order your Molex Series 52610 FFC-FPC Connector today and ensure secure, high-density connections for your electronic projects with reliable performance.
Frequently Asked Questions
Where can I buy MOLEX 526100733?
You can click on the BUY or RFQ button to purchase 526100733 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 526100733?
You can download the 526100733 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 526100733?
MOLEX
