MOLEX 901200800 C-Grid III Interconnect
The 2.54mm Pitch C-Grid III Interconnects are vertical, single-row headers designed for wire-to-board connections with 40 circuits. Featuring 0.38 micrometers gold selective plating, they offer high durability with multiple mating cycles and support current up to 3.0A per contact. Made of brass with nickel plating, these headers operate within -55°C to +125°C temperature range. They are RoHS compliant, halogen-free, and designed for through-hole mounting, suitable for various electronic assembly applications requiring reliable power and signal connections.
MOLEX 901200800 C-Grid III Interconnect Specifications:
- Pitch: 2.54mm
- Number of Circuits: 40
- Contact Material: Brass
- Plating: Gold, Nickel
- Current per Contact: 3.0A
- Maximum Voltage: 350V AC/DC
- Temperature Range: -55°C to +125°C
- Mounting: Through Hole
- Durability: Supports multiple mating cycles
- Color - Resin: Not specified
- Flammability: Not specified
- RoHS: Compliant
- Halogen-Free: No
- Package Type: Tray
- Orientation: Vertical
Buy the Buy Molex C-Grid III Interconnects Part Number 901200800 Online
Experience reliable and high-quality wire-to-board connections with Molex C-Grid III Interconnects. Featuring 2.54mm pitch, gold plating, and 40 circuits, these headers ensure excellent electrical performance and durability across various industrial and electronic applications. Designed for through-hole mounting, they support up to 3.0A current per contact with a maximum voltage of 350V. RoHS compliant and widely used in manufacturing, automation, and electronic assembly, these connectors provide excellent longevity and stable connection performance.
Get Molex 901200800 today—built for precision and long-lasting durability in wire-to-board connections with gold plating and high current capacity.
Frequently Asked Questions
Where can I buy MOLEX 901200800?
You can click on the BUY or RFQ button to purchase 901200800 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901200800?
You can download the 901200800 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901200800?
MOLEX
