MOLEX 901210125 Signal Header
The 2.54mm Pitch C-Grid III Header is a single-row, right-angle connector with 5 circuits and tin plating, suitable for wire-to-board signal connections. It features a compact design with a black resin housing, 94V-0 flammability rating, and operates within -55°C to +125°C temperature range. The connector is made of brass with tin plating on the contact points, ensuring excellent conductivity and corrosion resistance. It is configured for through-hole mounting, with a PCB tail length of 2.90mm, and supports a maximum current of 3.0A at 350V, ideal for various industrial and automation applications.
MOLEX 901210125 Signal Header Specifications:
- Pitch - Mating Interface: 2.54mm
- Number of Circuits (Loaded/Maximum): 5/5
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating/Termination: Tin
- Flammability: UL 94V-0
- Temperature Range - Operating: -55°C to +125°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 350V
- PCB Tail Length: 2.90mm
- Packaging Type: Tray
- Orientation: Right Angle
- Termination Interface: Through Hole
- Net Weight: 0.386g
- Guide to Mating Part: None
- Polarized to Mating Part: No
- Stackable: No
- Guide to Mating Part: None
Buy the Molex 90121U – Reliable Signal Headers for Industrial Applications
Purchase the Molex 90121 signal header online today for dependable electrical connections in industrial automation and equipment. Designed for through-hole mounting with a 2.54mm pitch and 5 circuits, this high-quality connector features tin-plated contacts for durability and corrosion resistance. Suitable for operating temperatures from -55°C to +125°C, it supports up to 3.0A current and 350V voltage. Ideal for wire-to-board signal connections in various industrial, automation, and electronic applications, ensuring secure and reliable performance.
Buy Molex 90121 now and experience unmatched reliability and performance in your industrial wiring and automation systems.
Frequently Asked Questions
Where can I buy MOLEX 901210125?
You can click on the BUY or RFQ button to purchase 901210125 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901210125?
You can download the 901210125 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901210125?
MOLEX
