MOLEX 901301124 Signal Connector
The C-Grid III Header is a dual-row, vertical, shrouded connector designed for signal and wire-to-board applications. Featuring 24 circuits, it is fully loaded with black resin and tin over nickel plating for corrosion resistance. Built from durable materials like brass and polyester, it supports up to 30 mating cycles and operates within a temperature range of -55°C to +125°C. The connector’s through-hole termination style, 2.54mm pitch, and polarizing design ensure reliable, secure connections in electronic assemblies, making it ideal for industrial and consumer device integration.
MOLEX 901301124 Signal Connector Specifications:
- Number of Circuits: 24
- Color: Black
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Flammability: 94V-0
- Durability: 30 mating cycles
- Operating Temperature Range: -55°C to +125°C
- Voltage Maximum: 350V AC/DC
- Current per Contact: 3.0A
- Pitch - Mating Interface: 2.54mm
- PC Tail Length: 2.90mm
- Wire Termination Style: Through Hole
- Guide to Mating Part: No
- Polarized to Mating Part: Yes
- Packaging: Tray
- RoHS Compliant: Yes
- UL Certification: E29179
- CSA Certification: LR19980
Buy the Molex 0901301124 – Reliable Signal Connector for Industrial Applications
Purchase the Molex 0901301124 online today and ensure your electronic projects benefit from high durability and reliable connectivity. This 24-circuit, dual-row, shrouded connector is designed for signal and wire-to-board applications. With a 2.54mm pitch, through-hole termination, and tin over nickel plating, it provides excellent corrosion resistance and secure mating. Suitable for environments from -55°C to +125°C, it supports up to 30 mating cycles. Easy to install and RoHS compliant, this connector guarantees dependable performance across a wide range of industrial and consumer electronics.
Get Molex 0901301124 today—built for precision, long-lasting durability, and reliable signal connections in industrial and electronic systems.
Frequently Asked Questions
Where can I buy MOLEX 901301124?
You can click on the BUY or RFQ button to purchase 901301124 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901301124?
You can download the 901301124 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901301124?
MOLEX
