MOLEX 901310128 PCB Header
The 2.54mm Pitch C-Grid III Header is a dual-row, vertical signal connector with 16 circuits and tin plating. It features a PCB header design suitable for wire-to-board applications. Made from durable polyester resin with brass metal components and tin plating for reliable electrical connections, it supports operating temperatures from -55°C to +125°C. The header is stackable, through hole termination style, and compatible with wave soldering processes. Its compact design includes a PCB tilt of 2.90mm and a maximum current of 3.0A per contact, rated up to 350V, ideal for signal and power connections in electronics.
MOLEX 901310128 PCB Header Specifications:
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Circuits (Loaded): 16
- Maximum Circuits: 16
- Material - Metal: Brass
- Material - Plating Mating & Termination: Tin
- Material - Resin: Polyester
- Color - Resin: Black
- Orientation: Vertical
- Stackable: Yes
- Guide to Mating Part No: None
- Lock to Mating Part: None
- PCB Locator: No
- PCB Retention: None
- Termination Interface: Through Hole
- Solder Process Data: Wave
- Lead-free Process Capability: Yes
- Temperature Range: -55°C to +125°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 350V
Buy the Molex Series 90131 C-Grid III PCB Header: 0901310128
Purchase the Molex PCB Header now to ensure high-quality electrical connections in your electronic projects. Designed with a 2.54mm pitch, dual-row configuration, and 16 circuits, it is perfect for signal and power applications. Made from durable polyester resin with brass and tin-plated components, this stackable, through-hole connector operates from -55°C to +125°C and supports up to 350V and 3.0A per contact. Available for quick online ordering to streamline your assembly process.
Buy Molex 0901310128 now and experience unmatched reliability and performance, ideal for signal and power connections in compact electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 901310128?
You can click on the BUY or RFQ button to purchase 901310128 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901310128?
You can download the 901310128 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901310128?
MOLEX
