MOLEX 901361108 C-Grid III Header

The C-Grid III Header is a vertical, shrouded, single-row connector designed for wire-to-board applications. It features 8 circuits with a tin/lead over nickel plating, ensuring reliable electrical connection and durability. Made with high-quality brass and polyester resin, it operates within a temperature range of -55°C to +125°C. The header supports a 2.54mm pitch, is CSA and UL certified, and is suitable for low-voltage applications up to 350V AC/DC and 3.0A per contact. Its compact design simplifies PCB assembly and provides secure mating connection with modular crimp housings.

View 901361108Datasheet [pdf]

Buy the Molex Series 90136 C-Grid III Interconnects: 901361108

Secure your electronic assemblies with the Molex C-Grid III Header. Featuring 8 circuits, tin/lead plating, and a 2.54mm pitch, this connector provides dependable wire-to-board connection within a temperature range of -55°C to +125°C. Crafted from high-quality brass and polyester, it is CSA and UL certified for safety and durability. Its shrouded design prevents mis-mating, and the compact form factor simplifies PCB layout, making it ideal for various electronic applications requiring reliable, board-to-wire connections with up to 350V and 3A per contact.

Order your Molex Series 90136 C-Grid III 901361108 vertical shrouded header today and ensure reliable, secure wire-to-board connections for your electronic projects.
