MOLEX 901512110 PCB Connector
The C-Grid III PC Board Connector is a reliable, dual-row, vertical PCB connector with 10 circuits and tin plating, designed for robust board-to-board applications. It features easy mating with 0.64mm square pins, and its construction ensures compliance with RoHS, ELV, and halogen-free standards. Manufactured with phosphor bronze and polyester insulation, it operates within -55°C to +125°C temperature range, supporting up to 3A per contact and 350V maximum voltage for secure electrical connections. Suitable for compact, high-density electronic systems requiring precise, durable connectors.
MOLEX 901512110 PCB Connector Specifications:
- Circuits: 10
- Color: Black
- Flammability: 94HB
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 0.867 grams
- Number of Rows: 2
- Orientation: Vertical
- PC Tail Length: 2.90mm
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Plating Min - Mating: Tin
- Plating Min - Termination: Tin
- Temperature Range - Operating: -55°C to +125°C
- Termination Interface: Style: Through Hole
- Current - Maximum per Contact: 3A
- Voltage - Maximum: 350V
- Process Temperature Max: 235°C
- Maximum Cycles at Max. Process Temperature: Not specified
- Lead-free Process Capability: Yes
Buy the Buy Molex PCB Connector Part Number 901512110 Online
Purchase the Molex PCB Connector 901512110 online for reliable and robust electrical connections in your electronic projects. This dual-row, 10-circuit connector features tin plating, is RoHS and halogen-free compliant, with a vertical orientation and 2.54mm pitch. Designed to operate within -55°C to +125°C, supporting up to 3A per contact and 350V maximum. Its durability and ease of installation make it ideal for high-density PCB applications, ensuring secure, precise, and long-lasting connections for industrial, consumer, and networking electronics.
Get Molex 901512110 today—built for precision, high-density applications, and long-lasting durability in connectivity solutions.
Frequently Asked Questions
Where can I buy MOLEX 901512110?
You can click on the BUY or RFQ button to purchase 901512110 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901512110?
You can download the 901512110 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901512110?
MOLEX
