MULTICOMP PRO 2211R04GSMCR Right Angle SMD Header
This 2.54mm pitch right-angle SMD header with cap offers a reliable 3A current rating and 250V voltage rating, suitable for compact electronic connections. Made from high-temp nylon with gold-plated copper alloy contacts, it features an insulation resistance of 1000MO min and withstands 600V AC for one minute. The component operates in temperatures from -40°C to +105°C, ensuring durability in various environments. Its single-row, 1-10 position configurations make it ideal for space-constrained PCB applications, providing secure, easy-to-mate connections with high conductivity and corrosion resistance.
MULTICOMP PRO 2211R04GSMCR Right Angle SMD Header Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mQ Max.
- Insulation Resistance: 1000MO Min.
- Withstanding Voltage: 600V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Materials and Finish: Copper Alloy, Gold Plated
- Insulator: High Temp. Plastic (Nylon 6T UL94V-0)
- Insulator Colour: Ivory
- Dimensions: 2.54mm pitch, single-row, 1 to 10 positions, standard length approximately 40.10 mm for 10 positions
- RoHS Compliant: Yes
Buy the Buy Multicomp Right Angle Header Part Number 2211R-04G-SM-CR Online
Secure your electronic projects with Multicomp's 2.54mm pitch right-angle SMD headers. Designed for durability and high performance, these headers feature gold-plated copper contacts, rated for 3A and 250V, with a wide operating temperature range from -40°C to +105°C. Ideal for compact PCBs, their single-row design offers flexibility in various applications. Easy to solder and reliable in performance, these headers ensure stable connections, resistance to corrosion, and compliance with RoHS standards. Order online now to enhance your electronics assembly with trusted quality.
Buy Multicomp 2211R-04G-SM-CR now and experience reliable PCB connections with high current capacity and robust construction.
