MULTICOMP PRO 2213R12GSM7576APR Right Angle Pin Header
The MULTICOMP PRO 2213R-12G-SM-7576APR is a right-angle pin header designed for surface mount applications. It offers a 2.54mm pitch and a double-row configuration with 12 positions, making it ideal for connecting components in space-constrained environments. Constructed with high-temperature Nylon 6T UL94V-0 insulator and gold-plated brass contacts, this header ensures reliable performance and durability in a range of industrial and consumer electronics applications. Its right-angle design simplifies routing and integration into PCB layouts.
MULTICOMP PRO 2213R12GSM7576APR Right Angle Pin Header Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 500V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Insulator: High Temp. Plastic (Nylon 6T UL94V-0)
- Insulator Colour: Black
- Contact Material: Brass
- Finish: Gold Plated
- A Dimension: 12.7mm
- B Dimension: 15.24mm
Buy the 2213R-12G-SM-7576APR MULTICOMP PRO Right Angle Pin Header | myMectronic
Purchase the MULTICOMP PRO 2213R-12G-SM-7576APR online for secure and reliable component sourcing.
