MULTICOMP PRO 2CT3002W12200 Waterproof Circular Connector
The 2CT3002-W12200 is a 12-way, 2A waterproof circular connector designed for panel mounting in industrial environments. Featuring a durable black nylon body, it includes gold-plated brass contacts and a gasket for sealing. This connector supports immersion in 1 meter of water for 30 minutes under IP67 rating, withstanding temperatures from -40°C to +100°C. It has a dielectric withstand voltage of 500VAC for one minute, suitable for harsh environments requiring reliable, water-resistant electrical connections with solder termination. Ideal for equipment exposed to challenging conditions.
MULTICOMP PRO 2CT3002W12200 Waterproof Circular Connector Specifications:
- Waterproof Rate: IP67, Immersed in 1m water for 30 minutes
- Electrical Characteristics: Current Rating 2A, Dielectric Voltage 500V AC for one minute, Temperature Range -40°C to +100°C
- Material: Body Nylon + GF Black, Contacts Brass 6y Inches Gold Plated Over Nickel Plating, Gasket EPDM
- Maximum Panel Thickness: 4mm
- Connector Type: Circular with solder termination, panel mounting
- Dimensions: Diameter approximately 15.6 mm, recommended panel cutout 4.0 mm thickness
- Environmental Compliance: Hazardous substance free, suitable for harsh environments
Buy the Buy Multicomp Waterproof Circular Connector Part Number 2CT3002W12200 Online
Order the waterproof circular connector 2CT3002W12200 online today for reliable performance in demanding environments. Designed for panel mounting, this 12-way, IP67 rated connector features gold-plated contacts, a durable nylon body, and optimal sealing with an EPDM gasket. Withstanding immersion up to 1 meter for 30 minutes and tolerating temperatures from -40°C to +100°C, it is ideal for industrial, automation, and harsh environment applications. Secure your connection needs with this robust, high-quality electrical component available for quick online purchase.
Buy Multicomp waterproof circular connector 2CT3002W12200 now and experience reliable waterproof connections for industrial applications in harsh environments.
