MULTICOMP PRO 2226A08 Crimp Housing Receptacle
The MULTICOMP PRO 2226A-08 is a receptacle connector housing designed for crimp connections. This 8-way housing is constructed with a Noryl (UL94V-1) insulator, providing excellent insulation and flame retardancy. It is ideal for applications in industrial automation, automotive systems, and consumer electronics where secure and reliable electrical connections are essential. The housing's dimensions and tolerances ensure consistent performance and ease of assembly.
MULTICOMP PRO 2226A08 Crimp Housing Receptacle Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 15mΩ Min.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 600V AC/minute
- Temperature Range: -25°C to +85°C
- Insulator Material: Noryl (UL94V-1)
- A Dimension (mm): 20.52
- B Dimension (mm): 17.78
- Circuits/Ways: 8
- Dimension A Tolerance: ±0.1 (11P to 20P)
- Dimension B Tolerance: ±0.2 (11P to 20P)
- General Tolerance X: ±0.2
- General Tolerance XX: ±0.15
