MULTICOMP PRO 2226B20 20 Way Latch Housing
The MULTICOMP PRO 2226B-20 is a miniature latch housing designed for wire-to-board connections. This 20-way connector offers a secure and reliable connection with its latching mechanism, ensuring minimal disconnection risk. Constructed with a polyester insulator and phosphor bronze contacts, it provides excellent electrical performance and durability. Suitable for applications in industrial automation, consumer electronics, and automotive systems, this connector supports wire gauges from 28AWG to 24AWG and operates within a temperature range of -25°C to +125°C. Its tin or gold-plated contacts ensure optimal conductivity and corrosion resistance.
MULTICOMP PRO 2226B20 20 Way Latch Housing Specifications:
- Connector Type: Wire to Board
- Contact Termination: Crimp
- Gender: Receptacle
- No. of Contacts: 20
- No. of Rows: 2
- Pitch Spacing: 2.54mm
- Withstand Voltage: 600V
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Max. Contact Resistance: 20mΩ
- Min. Insulation Resistance: 1,000MΩ
- Withstanding Voltage: 1,000V AC/minute
- Temperature Range: -25°C to +125°C
- Application Wires: 28AWG to 24AWG
- Insulator Material: Polyester
- Contact Material: Phosphor Bronze
- Finish: Tin Plated or Gold Plated
- A Dimension: 22.86mm
- B Dimension: 25.4mm
