MULTICOMP PRO 2N5320 NPN Power Transistor
The 2N5320 is a 75V silicon NPN medium power transistor suitable for medium power amplifier and switching applications. It offers reliable performance for industrial use and is ideal for power switching and low-frequency device applications. With high collector current capacity of 2A, low saturation voltage of 0.5V, and maximum junction temperature of +200°C, this transistor ensures efficient operation in various electronic circuits. Its TO-39 metal package provides durability and heat dissipation, making it ideal for general-purpose, industrial, and automation power control tasks, ensuring robustness and longevity.
MULTICOMP PRO 2N5320 NPN Power Transistor Specifications:
- Collector-Emitter Voltage: 75V
- Collector Current: 2A
- Base Current: 1A
- Total Device Dissipation: 1W (at 25°C), Derate above 25°C 5.71mW/°C
- Maximum Junction Temperature: +200°C
- Storage Temperature Range: -65°C to +200°C
- Junction to Ambient: 175°C/W
- Junction to Case: 17.5°C/W
- Collector-Base Voltage: 100V
- Emitter-Base Voltage: 7V
- Collector-Emitter Saturation Voltage: 0.5V
- Base-Emitter Voltage: 1.1V
- Small-Signal Current Gain, hte: Not specified
- Switching Time: Turn-on approx. 80ns, Turn-off approx. 800ns
- Package: TO-39 Metal
- RoHS Compliant: Yes
Buy the Multicomp Series 2N5320 NPN Transistor: 75V 2A Power Switch
Purchase the Multicomp Series 2N5320 NPN power transistor online today for your industrial and automation projects. This versatile device offers a maximum collector-emitter voltage of 75V and a continuous collector current of 2A, making it suitable for power switching and amplifier circuits. Encased in durable TO-39 metal packaging, it provides excellent heat dissipation and reliability. Its low saturation voltage of 0.5V and high junction temperature tolerance ensure efficiency and longevity in demanding environments. Get this high-quality transistor now for consistent, dependable performance and industrial-grade durability, all through our easy online shopping experience.
Order your Multicomp Series 2N5320 NPN transistor today and ensure reliable performance in power switching and amplification applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2N5320?
You can click on the BUY or RFQ button to purchase 2N5320 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2N5320?
You can download the 2N5320 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2N5320?
MULTICOMP PRO
