MULTICOMP PRO 5504F125P02A03 D-Sub Connector
The 5504F1-25P-02A-03 is a 25-position right-angle standard D-sub connector designed for robust electrical connections in computing and industrial automation. It features gold-plated brass contacts for excellent conductivity, a tin-plated copper solder tail for secure attachment, and a nickel-plated iron shell for durability. Made from high-temperature plastic, it withstands harsh environments with an operating temperature range from -40°C to +85°C. The connector's 8.08mm footprint and PCB mount make it ideal for space-constrained electronic assemblies requiring reliable, high-performance connections.
MULTICOMP PRO 5504F125P02A03 D-Sub Connector Specifications:
- Current Rating: 8A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 30mΩ Max.
- Insulation Resistance: 5,000MO Min.
- Withstanding Voltage: 1,000V AC/Minute
- Operating Temperature Range: -40°C to +85°C
- Materials and Finish: High Temp. Plastic insulator, Copper Alloy contact, Gold plated on Contact, Tin plated on Solder Tail, Nickel plated Iron shell
- Dimensions: Footprint 8.08mm, Mounting hole size 3.2x2mm, standard 25-position layout
- Connector Type: D-Sub Male, Right Angle PCB Mount
- Application: Computing, Peripherals, Industrial Equipment
Buy the Buy multicomp D-Sub Connectors Part Number 5504F125P02A03 Online
Enhance your electronic assemblies with the high-quality 5504F1-25P-02A-03 D-Sub connector. Featuring gold-plated contacts, a durable shell, and a PCB mount design, it ensures reliable, corrosion-resistant connections. Its compact footprint of 8.08mm makes it perfect for limited space applications in computers, automation, and instrumentation. The connector's high-temperature plastic insulator and solder termination provide added durability and stability. Streamline your assembly process and ensure long-term performance by purchasing this trusted D-Sub connector online today.
Buy multicomp 5504F125P02A03 now and experience reliable high-current connections with durable construction suitable for industrial and computing applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 5504F125P02A03?
You can click on the BUY or RFQ button to purchase 5504F125P02A03 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 5504F125P02A03?
You can download the 5504F125P02A03 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 5504F125P02A03?
MULTICOMP PRO
