MULTICOMP PRO 5504F137S02A03 D-Sub Receptacle
The 5504F1-37S-02A-03 is a 37-position, 3A right-angle D-subminiature female receptacle with gold-plated phosphor bronze contacts. It features a high-temperature plastic insulator, an 8.08mm footprint, and solder termination, making it suitable for industrial applications. This PCB-mounted connector is part of the 5504 series, designed for reliable performance in demanding environments.
MULTICOMP PRO 5504F137S02A03 D-Sub Receptacle Specifications:
- Number of Positions: 37
- Current Rating: 3A
- Voltage Rating: 250V AC/DC
- Contact Resistance: 30mΩ Max.
- Insulation Resistance: 5,000MΩ Min.
- Withstanding Voltage: 1,000V AC for One Minute
- Operating Temperature Range: -40°C to +85°C
- Material: PBT Insulation, Copper Alloy Contacts, Nickel-plated Shell
- Contact Plating: Gold on Contact Area, Tin on Solder Tail
- Thread Size: #4—40UNC
- Footprint: 8.08mm
- Dimensions: Varying by pin count: 9way 16.33x24.99x30.81mm, 15way 24.66x33.32x39.14mm, 25way 38.38x47.04x53.04mm, 37way 54.83x63.5x69.32mm
Buy the Multicomp Series D-Sub Receptacle: 37Way 5504F1-37S-02A-03
Purchase the durable and high-performance D-Sub Receptacle 5504F1-37S-02A-03 online to ensure reliable connections in your industrial or electronic projects. Featuring 37 positions, gold-plated contacts, and a compact PCB right-angle design, this connector provides excellent electrical performance and corrosion resistance. Its robust construction with high-temperature plastic insulator and solder termination makes it suitable for demanding environments. Order now for fast delivery and enhance your electronic assembly with a trusted, high-quality connector designed to meet professional standards for longevity and reliability.
Get Multicomp Series D-Sub Receptacle 5504F1-37S-02A-03 today—built for industrial reliability and durability.
