MULTICOMP PRO 7030101 Red LED Lamp
The 703-0101 is a 5mm round LED lamp with a high-intensity red emission, constructed with AlGaAs chips and red clear epoxy resin for durability. It features a power dissipation of 78mW, a maximum forward voltage of 2.4V at 20mA, and a luminous intensity of up to 600 med. Operating efficiently within -25°C to 85°C, it offers a viewing angle of 15 degrees, with a peak wavelength of 660nm and a dominant wavelength of 643nm. Suitable for indicator lighting and industrial applications requiring reliable red illumination.
MULTICOMP PRO 7030101 Red LED Lamp Specifications:
- Power Dissipation: 78 mW
- Reverse Voltage: 4 V
- Forward Current: 30 mA
- Reverse Leakage Current: 100 pA
- Peak Current: 100 mA (1/10 Duty Cycle, 0.1ms Pulse)
- Operating Temperature Range: -25°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Soldering Temperature: Dip Soldering 260°C for 5 sec, Hand Soldering 350°C for 3 sec
- Luminous Intensity: 300 to 600 med
- Forward Voltage: 1.9 to 2.4 V
- Peak Wavelength: 660 nm
- Dominant Wavelength: 643 nm
- Viewing Angle: 15 degrees
- Spectrum Line Halfwidth: 20 nm
Buy the Buy Premier Led Lamp Part Number 7030101 Online
Experience reliable illumination with this high-quality 5mm red LED lamp, featuring a durable epoxy resin and AlGaAs chip construction. It delivers bright output with luminous intensity up to 600 med, low power consumption, and robust operation from -25°C to 85°C. Perfect for indicator lights, panel displays, and industrial applications, this LED offers stable performance, compact size, and excellent electrical characteristics. Easily order online to enhance your electronic or industrial projects with this efficient, long-lasting lighting component.
Get Premier LED Lamp Part Number 7030101 today—built for consistent brightness and long-lasting durability in industrial settings.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 7030101?
You can click on the BUY or RFQ button to purchase 7030101 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 7030101?
You can download the 7030101 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 7030101?
MULTICOMP PRO
