MULTICOMP PRO 8FSM09P30N1FEC D Sub Connector Plug
The MULTICOMP PRO 8FSM09P-30N1-FEC is a D-sub connector within the 8F series, specifically designed for applications requiring Insulation Displacement Connector (IDC) and Insulation Displacement Termination (IDT) capabilities. This connector features 9 contacts and is engineered for secure and reliable data transmission in industrial automation, networking, and computer peripheral connections. The gold-plated contacts provide excellent conductivity and corrosion resistance, ensuring long-term performance. Its robust construction and standardized D-sub form factor make it compatible with a wide range of equipment and systems, simplifying integration and maintenance. The connector is ideal for applications where a compact and dependable connection is essential.
MULTICOMP PRO 8FSM09P30N1FEC D Sub Connector Plug Specifications:
- Current Rating: 1 Ampere Min.
- Insulation Resistance: 1,000MΩ (at 500V DC) Min.
- Dielectric Withstanding Voltage: 500V AC for one minute
- Operating Temperature: -55°C to 105°C Max.
- Contact Resistance: 15mΩ
- Insulator Material: PBT with glass-fibre reinforced
- Contact Material: Brass
- Contact Plating: Gold over nickel
- Wire Size: 26 and 28 stranded, 1.27mm conductor centre flat cable
- B Dimension: 30.8(1.212)
- Rear Mounting: 20.47(0.806)
- Front Mounting: 22.2(0.874)
