MULTICOMP PRO MC302472M120B20C0B Ceramic Capacitor
Radial leaded ceramic disc capacitors are reliable electronic components known for their stability and excellent dielectric properties. Widely used in various circuits, these capacitors offer high precision, stability, and compact size, making them ideal for diverse electronic applications. They feature high voltage ratings of up to 3 KV, with capacitance values ranging from 100 pF to 170 pF. Constructed with epoxy resin coating and lead diameters of 0.6 mm, they meet rigorous testing standards for withstand voltage, insulation resistance, and temperature endurance, ensuring durability and optimal performance in demanding environments.
MULTICOMP PRO MC302472M120B20C0B Ceramic Capacitor Specifications:
- Capacitance range: 100 pF to 170 pF
- Rated Voltage: 3 KV de
- Lead Diameter: 0.6 mm
- Lead Length: 20 mm
- Temperature Range: +10°C to +85°C
- Maximum Product Diameter: 12 mm
- Tolerance: ±20%
- Dielectric Material: Ceramic (Z5U class)
- Insulation Resistance: Minimum 10,000 MΩ
- Withstand Voltage: 6 KV for 1-5 seconds
- Dissipation Factor: below 2.5%
- Humidity Resistance: Up to 95% at 40°C for 500 hours
- Soldering Temperature: 260°C for 5 seconds
- Test Conditions: 5°C to 35°C, 45%-85% humidity
Buy the Buy multicomp Ceramic Disc Capacitor Part Number MC302472M120B20C0B Online
Purchase your multicomp Ceramic Capacitor MC302472M120B20C0B online today for high-voltage stability, excellent dielectric properties, and durable epoxy resin coating. Designed for precision electronic applications, it offers a capacitance of 120 pF and a rated voltage of 3 KV, ensuring reliable operation under demanding conditions. With robust insulation resistance and tested withstand voltage, this capacitor guarantees long-term performance in high-reliability circuits. Easy ordering process, prompt delivery, and trusted quality make it the ideal choice for your high-voltage electronic projects and maintenance needs.
Order your multicomp SeriesMC302472M120B20C0B ceramic disc capacitor today and ensure reliable performance with high voltage stability and precision.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC302472M120B20C0B?
You can click on the BUY or RFQ button to purchase MC302472M120B20C0B from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC302472M120B20C0B?
You can download the MC302472M120B20C0B datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC302472M120B20C0B?
MULTICOMP PRO
