MULTICOMP-PRO ABT425RC Electro Mechanical Transducer
The ABT-425-RC is an electro-mechanical transducer designed for surface mounting, operating at a resonant frequency of 2400Hz with a sound output level of 80dB at 10cm. Suitable for industrial applications, it features a black LCP housing, operates between 1-3Vp-p with a rated voltage of 1.5Vp-p, and consumes less than 30mA current. Its compact design weighs approximately 2g, performs well in temperatures from -20°C to +70°C, and is ideal for sound signaling in control systems requiring reliable performance.
MULTICOMP-PRO ABT425RC Electro Mechanical Transducer Specifications:
- Rated Voltage (Vp-p): 1.5Vp-p
- Operating Voltage: 1- 3Vp-p
- Rated Current: < 30mA
- Sound Output level @10cm: 80dB
- Resonant Frequency: 2400Hz +400Hz
- Coil Resistance: 150 +30
- Housing Material: Black LCP
- Operating Temperature: -20°C to +70°C
- Storage Temperature: -30°C to +80°C
- Weight: 2g
- Dimensions: Millimetres
- Tolerance: +0.5mm
Buy the Electro Mechanical Transducer – Reliable Sound Signal for Industrial Applications
Enhance your industrial signaling with the electro-mechanical transducer designed for reliable sound output in control systems. The ABT-425-RC features a resonant frequency of 2400Hz and provides an 80dB sound level at 10cm. Its compact black LCP housing ensures durability in temperatures from -20°C to +70°C. Easy to install with low current consumption, it is ideal for various automation and control applications requiring consistent sound signaling in harsh environments. Purchase online today for fast, reliable delivery.
Order your multicomp series ABT-425-RC today and equip your control systems with dependable, high-performance sound signaling components.
