MULTICOMP PRO BCX5416 High Power NPN Transistor
The BCX54, BCX55, and BCX56 are NPN silicon transistors designed for AF driver and output stages, offering high collector current and low saturation voltage. These transistors feature collector-base and collector-emitter breakdown voltages up to 100V, with a maximum collector current of 1A and peak of 15A, making them suitable for high-power switching applications. Encased in SOT-89 packages, their key characteristics include a transition frequency of 100 MHz and total power dissipation of 500mW at 130°C. They provide reliable performance in low voltage, high-speed switching circuits with excellent thermal stability.
MULTICOMP PRO BCX5416 High Power NPN Transistor Specifications:
- Collector-Base Voltage: 45V to 100V depending on model
- Collector-Emitter Voltage: 45V to 80V depending on model
- Emitter-Base Voltage: 5V
- DC Collector Current: 1A
- Peak Collector Current: 15A
- Base Current: 100mA
- Peak Base Current: 200mA
- Total Power Dissipation: 500mW at 130°C
- Transition Frequency: 100 MHz
- Package: SOT-89
- Dimensions (mm): Length 45-47, Width 23-27, Height 1.55-1.75, Typical lead length 4.5mm
- Operating Temperature Range: -65°C to +150°C
- Storage Temperature: -65°C to +150°C
Buy the Buy Silicon High Power NPN Transistor Part Number BCX54/BCX55/BCX56 Online
Purchase the BCX54, BCX55, and BCX56 NPN silicon transistors online today. Designed for AF driver circuits, these high-performance transistors deliver high collector current with low saturation voltage. Encased in compact SOT-89 packages, they support up to 1A DC current and peak 15A, with a transition frequency of 100 MHz. Ideal for high-speed switching and audio amplifier applications, ensuring reliable operation under demanding conditions. Buy now to enhance your electronic project with long-lasting, efficient power transistors.
Get BCX54/BCX55/BCX56 today—built for high-speed switching and long-lasting durability in powerful electronic circuits.
Frequently Asked Questions
Where can I buy MULTICOMP PRO BCX5416?
You can click on the BUY or RFQ button to purchase BCX5416 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part BCX5416?
You can download the BCX5416 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of BCX5416?
MULTICOMP PRO
