MULTICOMP-PRO 8FSM37S30N4FEC Datasheet & Stock
The 8FSM37S-30N4-FEC is a 37-way, 1A metal unthreaded IDC D-subminiature socket featuring gold-over-nickel plated phosphor bronze contacts. It is part of the 8FSM series female D-sub connector line, with a plastic through-hole metal shell and a PBT plus glass-fiber reinforced insulator. The socket supports 28 and 26 AWG stranded wire gauges, suitable for 1.27mm conductor flat cable. Key specifications include a maximum contact resistance of 15 milliohms, minimum insulation resistance of 1000 Megaohms, and a dielectric withstanding voltage of at least 500 VAC for one minute. It operates within a temperature range of -55°C to +105°C. The product is well-rated with a 4.6-star customer rating from Multicomp Pro, which offers a 12-month limited warranty. Approximately 96% of customers would recommend this product.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO 8FSM37S30N4FEC?
You can click on the BUY or RFQ button to purchase 8FSM37S30N4FEC from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part 8FSM37S30N4FEC?
You can download the 8FSM37S30N4FEC datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of 8FSM37S30N4FEC?
MULTICOMP-PRO
