MULTICOMP PRO ECW15 enameled copper wire
The ECW1.5 enameled copper wire features a 15 AWG (16 SWG) conductor with a polyurethane insulation coating for durability and flexibility. Ideal for manufacturing small motors, transformers, and relays, it operates at a maximum temperature of 120°C, with a melting point of 480°C. Compliant with BS4520 standards, the wire is made from soft grade 2 enameled copper in accordance with BS EN 60317/20, ensuring excellent electrical and mechanical properties suitable for automated soldering equipment and various industrial applications. The wire's design emphasizes reliability and performance in demanding environments.
MULTICOMP PRO ECW15 enameled copper wire Specifications:
- Conductor Gauge: 15 AWG (16 SWG)
- Conductor Diameter: 1.5 mm
- Insulation Coating: Polyurethane
- Insulation Thickness: 0.07 mm
- Maximum Operating Temperature: 120°C
- Melting Point: 480°C
- Electrical Resistivity at 20°C: 0.0172410 mm·Ω/m
- Specific Weight: 8.89 g/cm³
- Temperature Coefficient: 0.00694°C
- Certifications: BS4520, BS EN 60317/20
- Material: Soft grade 2 enameled copper
- Compliance: IEC 60317-0-1:2014, IEC 60317-51, NEMA MW 82-C
- Dimensions: Conductor diameter 1.5 mm, insulation thickness 0.07 mm
Buy the Buy multicomp enameled copper wire Part Number ECW15 Online
Purchase multicomp ECW15 enameled copper wire online today and ensure your manufacturing processes benefit from durable, high-quality wire designed for small motors, transformers, and relays. Featuring polyurethane insulation, this wire offers excellent flexibility and high-temperature tolerance up to 120°C. Its compliance with BS standards guarantees reliability for industrial applications. Make your order now through Newark, Farnell, or Element14 and enjoy fast delivery, competitive pricing, and the assurance of top-grade enameled copper suitable for automated soldering and demanding environments.
Buy multicomp ECW15 now and experience unmatched reliability and performance in industrial motor and transformer manufacturing.
Frequently Asked Questions
Where can I buy MULTICOMP PRO ECW15?
You can click on the BUY or RFQ button to purchase ECW15 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part ECW15?
You can download the ECW15 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of ECW15?
MULTICOMP PRO
