MULTICOMP-PRO GBU2508F Bridge Rectifier
This glass passivated bridge rectifier offers low forward voltage drop and high surge overload capacity of 350 amperes peak, making it ideal for high-current applications. Designed for use on printed circuit boards, it features reliable molded plastic construction with UL 94V-0 flammability rating, suitable for any mounting position. Rated at 800V peak reverse voltage, with a maximum RMS voltage of 560V and a DC blocking voltage of 800V, it supports continuous operation from -55°C to +150°C. Rated at 4.2A RMS at 25°C without heatsink, it handles surge currents up to 350A, providing robust performance for industrial power rectification.
MULTICOMP-PRO GBU2508F Bridge Rectifier Specifications:
- Maximum Recurrent Peak Reverse Voltage: 800V
- Maximum RMS Voltage: 560V
- Maximum DC Blocking Voltage: 800V
- Maximum Average Forward Current: 4.2A (without heatsink)
- Peak Forward Surge Current: 350A
- Maximum Forward Voltage at 12.54V DC: 0.95V
- Maximum DC Reverse Current at 25°C: 10A
- Operating Temperature Range: -55°C to +150°C
- Storage Temperature Range: Not specified
- Dimensions: 437mm x 139mm x 126mm (Millimeters), 17.27in x 5.47in x 4.96in
- Mounting Position: Any
- Material: Molded plastic, glass passivated
- Flammability: UL 94V-0
- Peak Surge Current (t<8.3ms): 200A
- Typical Junction Capacitance: 70pF
Buy the Multicomp GBU2508F – Reliable Bridge Rectifier for Industrial Applications
Purchase the multicomp GBU2508F bridge rectifier online today and benefit from its high current capacity, low forward voltage, and robust surge handling. Perfect for industrial power conversions, circuit protection, and high-current applications, this reliable component ensures long-lasting performance under demanding conditions. Its compact design, UL 94V-0 flame rating, and versatility in mounting positions make it an excellent choice for engineers and technicians seeking efficiency and durability. Order now for prompt delivery and enhance your power systems with confidence.
Buy multicomp GBU2508F now and experience unmatched reliability and high surge capacity for industrial power rectification.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO GBU2508F?
You can click on the BUY or RFQ button to purchase GBU2508F from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part GBU2508F?
You can download the GBU2508F datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of GBU2508F?
MULTICOMP-PRO
