MULTICOMP PRO HC49S1230507030ATF Crystal Oscillator
The HC49S-12-30-50-70-30-ATF is a compact surface-mount crystal measuring 10.9 x 4.65 mm, designed for limited space applications. It features 30 and 50 ppm frequency stability, and operates in the fundamental vibration mode. This crystal has a maximum equivalent series resistance of 50Ω, a shunt capacitance up to 5pF, and an insulation resistance of 500MΩ at 100V DC. Its low profile and high resistance weld metal case make it suitable for clock, timing, industrial, communication, and networking devices requiring precise frequency control.
MULTICOMP PRO HC49S1230507030ATF Crystal Oscillator Specifications:
- Nominal Frequency Range: 10 to 30 MHz
- Vibration Mode: Fundamental (AT)
- Frequency Tolerance at 25°C: +20, +30, or +50 ppm
- Temperature Stability: +30 or +50 ppm
- Operating Temperature Range: -10°C to +60°C
- Storage Temperature Range: -20°C to +70°C
- Load Capacitance: 8 pF to 32 pF or series
- Equivalent Series Resistance: Max 50Ω
- Shunt Capacitance: 5pF maximum
- Drive Level: 200μW maximum (<5 MHz), 100μW maximum (>5 MHz)
- Insulation Resistance: 500MΩ minimum at 100V DC
- Dimensions: 10.9 x 4.65 mm
- Material: Metal case with resistance weld
- RoHS Compliant
- Supply Format: Taped and reeled for automated assembly
- Application: Clock and timing, industrial controls, communication equipment, networking devices
Buy the Multicomp HC49S-12-30-50-70-30-ATF – Reliable Crystal for Industrial Applications
Purchase the Multicomp HC49S crystal oscillator online today to ensure high accuracy and reliability in your timing and frequency control applications. Its compact size, low profile design of just 10.9 mm by 4.65 mm, and robust resistance weld metal case make it ideal for space-constrained industrial, networking, and communication devices. Engineered for precision with frequency stability options of 30 or 50 ppm and operating temperature ranges from -10°C to 60°C, this crystal guarantees long-term performance and stability in demanding environments.
Get Multicomp HC49S-12-30-50-70-30-ATF today—built for precision, space-saving design, and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49S1230507030ATF?
You can click on the BUY or RFQ button to purchase HC49S1230507030ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49S1230507030ATF?
You can download the HC49S1230507030ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49S1230507030ATF?
MULTICOMP PRO
