MULTICOMP PRO HC49S7372815306018ATF Crystal Oscillator
The HC49S-7.3728-15-30-60-18-ATF is a surface-mount crystal measuring 10.9 x 4.65 mm, designed for applications requiring a low profile and high precision. It features 30 and 50 ppm tolerances, a resistance weld metal case, and operates in the fundamental vibration mode. The crystal has a maximum equivalent series resistance of 80 ohms, a maximum shunt capacitance of 5 pF, and a minimum insulation resistance of 500 megaohms at 100 VDC. Suitable for clock and timing, industrial, and communication applications, it is part of the HC49S series, ideal for board space-constrained designs.
MULTICOMP PRO HC49S7372815306018ATF Crystal Oscillator Specifications:
- Nominal Frequency Range: 3.5 to 32 MHz
- Vibration Mode: Fundamental (AT), 3rd Overtone (AT)
- Frequency Tolerance at 25°C: +20, +30, or +50 ppm (Options: +10ppm, +15ppm)
- Temperature Stability: +30 or +50 ppm
- Operating Temperature Range: -10°C to +60°C (Option: -20°C to +70°C)
- Storage Temperature Range: -20°C to +70°C (Option: -30°C to +80°C)
- Load Capacitance: 8 pF to 32 pF or series
- Equivalent Series Resistance: Max 80 ohms (at frequencies up to 30 MHz)
- Shunt Capacitance: 5 pF maximum
- Drive Level: 200 µW maximum (<5 MHz); 100 µW maximum (>5 MHz)
- Insulation Resistance: ≥ 500 Megaohms at 100 VDC
- Aging: ±5 ppm per year
- Dimensions: 10.9 mm length, 4.65 mm width, low profile design
Buy the Multicomp HC49S – Reliable Crystals for Industrial Applications
Order the multicomp HC49S crystal online today and enhance your designs with a low profile, high-precision oscillator. This surface-mount component offers excellent stability, resist weld case construction, and wide temperature survival, making it perfect for space-conscious industrial, communication, and microcontroller applications. With a broad frequency range, excellent aging characteristics, and easy procurement through our trusted online platforms, it’s the ideal choice for reliable and accurate timing needs in demanding environments. Purchase now for fast delivery and consistent performance.
Buy multicomp HC49S crystal now and experience unmatched reliability and performance in your industrial, microcontroller, and communication projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49S7372815306018ATF?
You can click on the BUY or RFQ button to purchase HC49S7372815306018ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49S7372815306018ATF?
You can download the HC49S7372815306018ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49S7372815306018ATF?
MULTICOMP PRO
