MULTICOMP PRO HGBJ3510 Three-Phase Bridge Rectifier
The HGBJ3510 is a high-reliability, glass passivated three-phase bridge rectifier designed for power supply applications, PWM converters, and DC motors. Featuring low forward voltage drop, insulation voltage of 2,500V, and small size with lightweight construction, it ensures high thermal conductivity and low temperature rise. Suitable for use in resistive or inductive loads at 25°C ambient temperature, it supports maximum repetitive peak voltages of 1,000V, and surge currents up to 400A. Its robust design with thermal resistance of 0.8°C/W makes it ideal for industrial AC/DC conversion needs.
MULTICOMP PRO HGBJ3510 Three-Phase Bridge Rectifier Specifications:
- Peak Repetitive Voltage VRRM: 1,000V
- Peak Non-Repetitive Reverse Voltage VrsM: 1,100V
- Maximum Average Forward Current Iw: 38A
- Peak Forward Surge Current t=8.3ms: 400A
- Maximum Forward Voltage Drop: 14V at Vr
- Reverse Peak Current Vr=VrrM: 5pA at 25°C, 3mA at 150°C
- Isolation Voltage from Case to Lead Viso: 2,500V
- Thermal Resistance: 0.8°C/W
- Operating Temperature Range: -55°C to +150°C
- Mounting Torque: 0.8 N·m
- Weight: 10g
- Dimensions: 1.874(47.6) x 1.579(40.1) inches (various dimensions provided)
Buy the Multicomp Pro HGBJ3510 – Reliable Bridge Rectifier for Industrial Applications
Order the Multicomp Pro HGBJ3510 online now to experience a high-reliability, glass passivated bridge rectifier designed for industrial power supply, PWM converters, and DC motors. Featuring a max voltage of 1,000V, surge current of 400A, and insulation voltage of 2,500V, it ensures efficient and safe AC/DC conversion. This compact, lightweight rectifier with excellent thermal performance supports continuous operation in demanding environments, making it the ideal choice for manufacturers and engineers seeking durable, high-performance power rectification components for their commercial or industrial systems.
Get Multicomp Pro HGBJ3510 today—built for precision, high thermal conductivity, and long-lasting durability. Perfect for industrial power supply and motor drives.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HGBJ3510?
You can click on the BUY or RFQ button to purchase HGBJ3510 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HGBJ3510?
You can download the HGBJ3510 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HGBJ3510?
MULTICOMP PRO
