MULTICOMP PRO MC000025 PCB Terminal Block
The MC000025 is a 12-position, 3.81mm pitch PCB terminal block featuring tin-plated brass terminals and a green polyamide 66 insulating body. It is designed with a through-hole right-angle configuration, supporting wire gauges up to 16 AWG with a wire strip length of 4 to 5mm. The terminal block uses a screw connection for secure wire-to-board contact, offers an insulation resistance of over 2000 megaohms, and operates within a temperature range of -55°C to +105°C. Suitable for various electronic applications, it is part of Multicomp Pro's product line, which is rated 4.6 out of 5 stars, with a 12-month limited warranty and high customer satisfaction.
MULTICOMP PRO MC000025 PCB Terminal Block Specifications:
- Pitch: 3.81mm (0.15 inch)
- Number of Poles: 12
- Wire Range: 16 AWG
- Wire Strip Length: 4 to 5mm
- Operating Temperature: -55°C to +105°C
- Insulation Resistance: > 2000 MΩ at 500V DC
- Material: Polyamide 66 - Green
- Terminal Material: Brass, Tin Plated
- Screw Material: Steel, Nickel Plated
- Rated Current: 10A
- Rated Voltage: 300V AC
- Min. Withstand Voltage: 2000V AC
- Insulation Withstand Voltage: 2000V AC
- Torque: 2 lb-inch
Buy the Buy Multicomp PCB Terminal Part Number MC000025 Online
Secure your electronic wiring with the 12-position, 3.81mm pitch PCB terminal block from Multicomp. Featuring brass and steel construction, a green polyamide insulation body, supporting 16 AWG wires, and rated for -55°C to +105°C, this terminal ensures durability and performance. Its screw connection provides a reliable and easy-to-use interface, with insulation resistance over 2000 megaohms, ideal for various industrial and consumer electronics. Purchase online now for quick delivery and professional-grade connections.
Order your Multicomp 12-Position 3.81mm Pitch PCB Terminal Block today and ensure reliable wiring connections for your electronic projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000025?
You can click on the BUY or RFQ button to purchase MC000025 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000025?
You can download the MC000025 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000025?
MULTICOMP PRO
