MULTICOMP PRO MC000051 PCB Terminal Block
This 6.35mm PCB terminal block is designed for reliable electrical connections in industrial and control applications. Made with a green polyamide insulating body and brass tin-plated terminals, it supports wire ranges from 20 to 110 AWG and can handle up to 130A at 300V AC. The device features cage clamps, nickel-plated steel screws, and a pitch of 6.35mm for compact installation. Suitable for a temperature range from -40°C to +105°C, it ensures high insulation resistance and withstands voltages up to 2000V AC, making it ideal for robust electrical systems.
MULTICOMP PRO MC000051 PCB Terminal Block Specifications:
- Rating Current: 130A
- Rating Voltage: 300V AC
- Insulation Resistance: >2,000MQ at 500V DC
- Insulation withstand Voltage: 2,000V AC
- Operating Temperature: -40°C to +105°C
- Wire Range: 20 to 110 AWG
- Wire Strip Length: 78mm
- Screw Torque: 25.5 Ib-inch
- Pitch: 6.35mm (0.25")
- Material: Insulating body made of Polyamide 66 - Green
- Cage clamp: Steel, Ni plated
- Terminal: Brass, Tin plated
- Screw: Steel, Ni plated
- Dimensions: 6.35mm pitch, 12.7mm (2 Way), 19.05mm (3 Way)
- Temperature Range: -40°C to +105°C
Buy the Buy Multicomp 6.35mm PCB Terminal Block Part Number MC000051 Online
Enhance your electrical assemblies with the Multicomp 6.35mm PCB Terminal Block, supporting wire ranges from 20 to 110 AWG, rated at 130A and 300V AC. Crafted with a durable polyamide insulating body and tin-plated brass terminals, it ensures consistent, secure connections in industrial environments. Its robust construction withstands temperatures from -40°C to +105°C and withstands voltages up to 2000V AC for safety and reliability. Perfect for PCB assemblies requiring compact, high-current terminal solutions, available now for quick online purchase.
Get Multicomp MC000051 today—designed for reliable connections and high current capacity in industrial control systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC000051?
You can click on the BUY or RFQ button to purchase MC000051 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC000051?
You can download the MC000051 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC000051?
MULTICOMP PRO
