MULTICOMP-PRO MC002311 Solid State Relay Module
This single-channel DIN rail-mounted solid-state relay module provides reliable switching for AC loads up to 240VAC with control voltages from 4V to 32V DC. Its dielectric strength of 4000VACrms ensures high isolation safety, suitable for automation, control systems, and entertainment equipment. Featuring zero crossing technology for smooth switching, it supports load currents from 0.1A to 5A, with LED indicators for status. Compact and robust, it offers high surge capacity and excellent durability for industrial applications, optimizing control and automation processes.
MULTICOMP-PRO MC002311 Solid State Relay Module Specifications:
- Load Current Range: 0.1A to 5A
- Control Voltage Range: 4-15V DC, 15-32V DC, or 4-32V DC
- Maximum Load Voltage: 240V AC, 24-280V AC
- Dielectric Strength: 4000VACrms
- Insulation Resistance: 1000MQ
- Ambient Operating Temperature Range: -30°C to +80°C
- Ambient Storage Temperature Range: -30°C to +100°C
- Weight: 55g
- Maximum Surge Current: 160A (at 10ms)
- Maximum On-State Voltage Drop: 1.5Vrms
- Maximum Off-State Leakage Current: 5mA
- Isolation Voltage: 4000VACrms
- Control Input Current: 25mA
- Input Circuit Voltage: 4V DC to 15V DC or 15V DC to 32V DC
- Maximum Turn-On Time: 1/2 cycle + 1ms
- Maximum Turn-Off Time: 1/2 cycle + 1ms
Buy the Multicomp Pro MC002311 – Reliable Solid State Relay for Industrial Applications
Enhance your automation setup with the reliable solid-state relay module designed for industrial control systems. This DIN rail-mounted device supports AC loads up to 240VAC and control voltages from 4V to 32V DC. Its high dielectric strength of 4000VACrms ensures exceptional isolation, safety, and durability. Supporting load currents from 0.1A to 5A, it features zero crossing switching for minimal electrical noise. Easy to install with LED indicators for status, this module guarantees efficient performance for automation, factory automation, and entertainment equipment systems. Purchase online now for seamless integration into your control panels.
Get Multicomp Pro MC002311 today—built for precise control and long-lasting durability in automation and control systems.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC002311?
You can click on the BUY or RFQ button to purchase MC002311 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC002311?
You can download the MC002311 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC002311?
MULTICOMP-PRO
