MULTICOMP PRO MC003062 Precision Thin Film Resistor
These advanced thin film precision resistors boast very tight 0.1% tolerance, low Temperature Coefficient Resistance (TCR), and miniature size 0201. Suitable for high-accuracy electronic circuits, they feature alumina substrates with bottom, top, and edge electrodes, barrier layer, external electrode, resistor layer, overcoat, and marking for easy identification. Dimensions are around 0.58 mm in length and 0.29 mm in width, with a typical thickness of 0.23 mm. They are RoHS compliant, supporting overloads and operating voltages up to 15V and 30V respectively. Designed for reliable operation over a broad temperature range from -55°C to +155°C, and endurance testing ensures durability for critical applications.
MULTICOMP PRO MC003062 Precision Thin Film Resistor Specifications:
- Size: 0201 (0603)
- Resistance Tolerance: 0.1%
- Power Rating: 1/32 W at 55°C
- Maximum Operating Voltage: 15V
- Maximum Overload Voltage: 30V
- Ambient Temperature Range: -55°C to +155°C
- Temperature Coefficient Resistance (TCR): Low, exact value varies per model
- Dimensions: Length 0.58 mm ±0.05 mm, Width 0.29 mm ±0.05 mm, Thickness 0.23 mm ±0.05 mm
- Material: Alumina substrate with thin film resistor layer
- RoHS Compliance: Yes
- Durability: Endurance over 1000 hours at 70+2°C with minimal resistance change
- Insulation Resistance: >9999 MΩ applying 100VDC for 1 minute
- Solderability: 95% min. coverage at 245°C for 3 seconds
- Bending Strength: 3 mm amplitude for 10 seconds as per MIL-STD-202
- Soldering Method: IR reflow (max 3 cycles), Wave soldering allowed (max 2 cycles)
- Storage Conditions: 15-28°C, <80% R.H.
Buy the Buy Multicomp Precision Thin Film Resistors Part Number MC003062 Online
Order the high-precision thin film resistors online today to benefit from their tight 0.1% tolerance, low TCR, and compact 0201 size. Perfect for critical applications requiring exceptional accuracy, durability, and stability. These resistors support overloads up to 30V and operate seamlessly between -55°C and +155°C, ensuring reliable performance in diverse environmental conditions. Easy to integrate into automated assembly lines thanks to RoHS compliance, advanced thin film technology, and comprehensive testing for endurance. Secure your inventory now for consistent quality and long-term dependability.
Buy Multicomp MC003062 now and experience unmatched reliability and performance in high-accuracy electronic circuits.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC003062?
You can click on the BUY or RFQ button to purchase MC003062 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC003062?
You can download the MC003062 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC003062?
MULTICOMP PRO
