MULTICOMP PRO MC0125W1206149R9 Thick Film Resistor
The Multicomp Pro MC series thick film chip resistors offer resistance values from 1 ohm to 10 megaohms, including E96 and E24 values. Available in sizes 0402, 0603, 0805, and 1206, these small, lightweight resistors are suitable for wave and reflow soldering, reducing assembly costs. They provide maximum voltages up to 50V for smaller sizes and 200V for larger sizes, with tolerances of ±1%, ±2%, or ±5%. Operating from -55°C to +155°C, they feature TCR from ±400ppm/°C to ±100ppm/°C, with power ratings from 62.5mW to 125mW, and jumper options across all sizes.
MULTICOMP PRO MC0125W1206149R9 Thick Film Resistor Specifications:
- Resistance Range: 1Ω to 10MΩ
- Available Sizes: 0402, 0603, 0805, 1206
- Tolerance Ratings: ±1%, ±2%, ±5%
- Maximum Working Voltage: up to 50V (small sizes), 200V (larger sizes)
- Power Ratings: 62.5mW to 125mW
- Temperature Coefficient of Resistance: ±400ppm/°C (1Ω to 10Ω), ±100ppm/°C (>100Ω)
- Operating Temperature Range: -55°C to +155°C
- Jumpers: Available for all sizes
- Application: Suitable for both wave and reflow soldering, reducing assembly costs
Buy the Multicomp Thick Film Resistors – Reliable 1206 for Industrial Applications
Purchase Multicomp Pro thick film resistors online today to benefit from their high accuracy, wide resistance range, and compatibility with wave and reflow soldering. These resistors help reduce assembly costs while ensuring stable operation from -55°C to +155°C. Available in four standard sizes—0402, 0603, 0805, and 1206—and rated for voltages up to 200V, they are ideal for precision applications. Buy now and enjoy quick delivery with a 12-month warranty, making your manufacturing process more efficient and cost-effective.
Buy Multicomp Pro thick film resistors now and experience reliable performance across various resistance values and sizes.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC0125W1206149R9?
You can click on the BUY or RFQ button to purchase MC0125W1206149R9 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC0125W1206149R9?
You can download the MC0125W1206149R9 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC0125W1206149R9?
MULTICOMP PRO
