MULTICOMP PRO MC0125W12061680K Thick Film Resistor
This 1206-sized thick film chip resistor offers high reliability, low TCR, and excellent performance across various conditions. Suitable for surface-mount assembly, it features rated power of 0.125W, resistance ranges from 1Ω to 1MΩ, and tolerances of 1%. Its robust construction ensures stability during temperature cycling, humidity, and overload conditions, making it ideal for precise circuit applications in industrial and consumer electronics. The resistor combines a high purity alumina substrate with nickel and tin terminations, ensuring excellent solderability and durability in demanding environments.
MULTICOMP PRO MC0125W12061680K Thick Film Resistor Specifications:
- Size: 1206
- Power Max: 0.125W
- Resistance Range: 1Ω to 1MΩ
- Tolerance: 1%
- Temperature Coefficient: 1 to 10Q +400PPM/°C, 11 to 100Q +200PPM/°C, >100Q +100PPM/°C
- Rated Working Voltage: 200V
- Overload Voltage: 500V
- Temperature Cycling: Max. ±1%
- Humidity Resistance: Max. ±0.5%
- Load Life Stability: Max. ±1%
- Dielectric Withstanding Voltage: No flashover or insulation breakdown
- Solderability Coverage: Minimum 95%
- Terminal Bending & Soldering Heat: Max. ±0.05Ω
- Insulation Resistance: Min. 1,000MQ
- Construction: Alumina substrate with Ni and Sn terminations, Ag resistive element
Buy the Buy Multicomp Thick Film Resistor Part Number MC0125W12061680K Online
Order the high-quality thick film resistor online from authorized distributors and enjoy fast delivery, competitive pricing, and expert support. Designed for surface-mount applications, this resistor delivers excellent stability, low TCR, and durability under temperature, humidity, and overload stress. Whether you need a resistor for industrial control, consumer electronics, or embedded systems, this component offers precise resistance, easy soldering, and long-term reliability. Invest in proven electronics components to ensure your project’s success—shop now for fast, secure online ordering.
Buy Multicomp thick film chip resistor now and experience unmatched reliability and performance for your electronic circuits.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC0125W12061680K?
You can click on the BUY or RFQ button to purchase MC0125W12061680K from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC0125W12061680K?
You can download the MC0125W12061680K datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC0125W12061680K?
MULTICOMP PRO
