MULTICOMP-PRO MC25117 Power Relay
The MC25117 power relay features silver alloy contacts and a DPDT configuration, ideal for industrial applications requiring reliable switching. It supports a maximum power of 1250 VA or 120 W with a minimum load of 5 VDC at 100 mA. The relay's high contact resistance of 100 milliohms at 6 VDC / 1 A ensures stability, while its insulation resistance exceeds 1000 megaohms at 500 VDC. Operating times are quick, with a maximum of 15 ms for actuation and 8 ms for release. Rated for 10 million cycles, it guarantees long-term durability in demanding environments.
MULTICOMP-PRO MC25117 Power Relay Specifications:
- Contact Form: 2 form C (DPDT)
- Contact Material: Silver Alloy
- Contact Rating: Resistive: 5A 250V AC / 24V DC; Inductive: 5A 250V AC / 24V DC (Cos φ = 0.4, L/R = 7ms)
- Max Switching Voltage: 250V AC / 24V DC
- Max Switching Current: 5A
- Max Switching Power: 1250VA / 120W
- Min Switching Load: 5V DC, 100mA
- Max Contact Resistance: 100 milliohms at 6 VDC / 1 A
- Max Operating Time: 15 ms
- Max Release Time: 8 ms
- Insulation Resistance: 1000 megaohms at 500 VDC
- Dielectric Strength: 4000V AC, 1 min between coil and contacts
- Operating Temperature Range: -30°C to +70°C (540mW), +10°C to +55°C (720mW)
- Shock Resistance: 1000 m/s²
- Vibration Resistance: 100 m/s²
- Endurance: 10 million mechanical operations
- Humidity: 35% to 95%RH at +40°C
Buy the Buy Multicomp Power Relay Part Number MC25117 Online
Enhance your control systems with the reliable and durable Multicomp power relay MC25117. Featuring silver alloy contacts and a DPDT configuration, this relay supports up to 1250 VA or 120 W, ensuring high performance and longevity. With fast switching times of 15 ms operate and 8 ms release, it withstands 10 million cycles for long-term use. Its high insulation resistance, robust dielectric strength, and wide temperature range make it suitable for diverse industrial environments. Buy online now for quality and dependable operation.
Order your Multicomp Series MC25117 power relay today and ensure reliable switching performance in your industrial automation projects.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC25117?
You can click on the BUY or RFQ button to purchase MC25117 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC25117?
You can download the MC25117 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC25117?
MULTICOMP-PRO
