MULTICOMP PRO MC25133 Industrial DPDT PCB relay
The MC25133 is a high-reliability DPDT PCB relay featuring gold over silver alloy contacts and solder terminals. Ideal for industrial applications, it operates between -25°C and 70°C, with a maximum operating time of 7ms. The relay provides high sensitivity, with contact ratings of 2A at 120V AC/24V DC, and offers a Sealed plastic enclosure for durability and safety. It has a life expectancy of 100,000 electrical operations and 15 million mechanical cycles, making it suitable for control systems requiring long-term performance and precise switching capabilities.
MULTICOMP PRO MC25133 Industrial DPDT PCB relay Specifications:
- Contact Data: 2 form C, AuAg overlay, Ag Alloy, 2A at 120V AC/24V DC, Max. Switching Voltage 125V AC/30V DC, Max. Switching Power 120VA, 30W
- Electrical Life: 100,000 operations, Mechanical Life: 15 million operations, Contact Resistance: 50mΩ (Standard), 100mΩ (High Sensitivity)
- Insulation Resistance: 1000MΩ at 500V DC, Dielectric Strength: 750V AC between open contacts, 1000V AC coil-to-contacts
- Operate Time: max 7ms, Release Time: max 3ms, Operating Temperature: -25°C to 70°C, Shock Resistance: 1000 m/s²
- Vibration Resistance: 10-55Hz, 1.5mm double amplitude, Humidity: 35-95% RH at +40°C, Enclosure: Plastic sealed, Part Number: MC25133
Buy the Multicomp Series Relay: DPDT Low Signal Control with Gold Contacts MC25133
Enhance your control systems with this durable industrial relay featuring gold over silver alloy contacts, sealed plastic enclosure, and high sensitivity. Suitable for a wide temperature range, it offers excellent longevity with 100,000 electrical operations and 15 million mechanical cycles. Perfect for automation, robotics, and industrial equipment, this relay ensures precise switching and reliable performance in demanding environments. Buy online now to benefit from quick delivery and trusted quality, making it an essential component for your automation solutions.
Order your Multicomp Series MC25133 relay today and ensure reliable switching performance for industrial automation and control projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC25133?
You can click on the BUY or RFQ button to purchase MC25133 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC25133?
You can download the MC25133 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC25133?
MULTICOMP PRO
