MULTICOMP PRO MC25154 Power Relay
The MC25154 is a versatile power relay with SPST-NO contacts, providing 30A switching capacity suitable for industrial use. It features a plastic sealed enclosure for durability and is designed for through-hole mounting. Operating reliably from -30°C to 85°C, it handles up to 240V AC resistive load and 30A current, making it ideal for automation, control panels, and industrial equipment. This relay offers high contact reliability, with a long mechanical life of over 10 million cycles, ensuring dependable operation in demanding environments.
MULTICOMP PRO MC25154 Power Relay Specifications:
- Contact Form: SPST-NO
- Contact Material: Silver Alloy
- Max. Switching Voltage: 240V AC
- Max. Switching Current: 30A
- Max. Switching Power: 7500VA, 720W
- Max. Contact Resistance: 50mΩ (6V DC, 1A)
- Operate Temperature: -30°C to 85°C
- Dielectric Strength: 1500V AC, 1 min between open contacts
- Insulation Resistance: 1000MΩ at 500V DC
- Mechanical Life: 10,000,000 operations
- Electrical Life: 100,000 operations
- Coil Voltage: 12V DC, 24V DC
- Coil Resistance: 160Ω at 20°C (12V), 640Ω at 20°C (24V)
- Enclosure: Plastic sealed
- Mounting: Through-hole
- Shock Resistance: 100m/s²
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Buy the Multicomp Power Relay 25154 – Reliable Industrial Power Switching for Automation
Secure the Multicomp Power Relay 25154 today for reliable switching in industrial environments. With a 30A capacity, sealed enclosure, and a long mechanical life, this relay ensures consistent performance. Ideal for automation, control panels, and demanding manufacturing processes, its high dielectric strength and broad temperature range make it suitable for various industrial applications. Purchase online now to benefit from fast delivery and dependable operation, enhancing your system’s efficiency and safety.
Buy Multicomp Power Relay 25154 now and experience unmatched reliability and performance for your industrial control systems.
