MULTICOMP-PRO MC32833 Tactile Switch
The MC32833 tactile switch is a robust, through-hole SPST component with a brown actuator suitable for industrial and electronic applications. It features stainless steel and brass construction with silver plating for reliable contact performance. With an operating force of 160 grams-force, it ensures precise actuation and long-term durability, capable of handling up to 200,000 cycles. Designed to operate within a temperature range of -25°C to 70°C, this switch offers high insulation resistance and dielectric strength, making it ideal for demanding environments requiring reliable tactile feedback.
MULTICOMP-PRO MC32833 Tactile Switch Specifications:
- Contact Configuration: Single-Pole Single-Throw (SPST)
- Actuator: Brown
- Terminal Material: Silver-plated Brass
- Switch Material: Stainless Steel and UL94V-0 Nylon Thermoplastic
- Operating Force: 160 grams-force
- Cycle Life: Up to 200,000 cycles
- Operating Temperature Range: -25°C to +70°C
- Dielectric Strength: 250VAC for 1 minute
- Insulation Resistance: 100MΩ minimum at 500VDC
- Contact Resistance: 100mΩ maximum
- Rating: 50mA, 12VDC
- Max Load: 3kgf vertically for 15 seconds
- Dimensions and Mechanical: Stroke 0.35±0.1mm, Stop Strength Max 3kgf
- Connector: Stainless Steel and Brass, high durability
Buy the Buy Multicomp Pro Tactile Switch Part Number MC32833 Online
Purchase the high-quality Multicomp Pro tactile switch MC32833 online today for your electronic and industrial projects. Featuring a single-pole single-throw configuration, a durable stainless steel and brass construction, and a brown actuator, this switch guarantees reliable actuation with an operating force of 160 grams-force. Designed to endure up to 200,000 cycles, it operates efficiently within a temperature range of -25°C to 70°C, making it perfect for demanding environments. Enjoy fast delivery and secure online ordering today.
Order your Multicomp Pro MC32833 tactile switch today and ensure reliable performance in industrial and electronic applications with long cycle life.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MC32833?
You can click on the BUY or RFQ button to purchase MC32833 from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MC32833?
You can download the MC32833 datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MC32833?
MULTICOMP-PRO
