MULTICOMP PRO MC33177 PTC Resettable Fuse
The radial leaded PTC resettable fuse by multicomp is a solid-state device designed for overcurrent protection in electronic circuits. It features low hold current, high max voltage of up to 90V, and is suitable for telecom and various electronic applications. Made with solderable tin-plated copper leads, it withstands temperatures from -40°C to 85°C and complies with RoHS and UL standards. Its compact radial design ensures reliable operation, quick trip response, and durability, making it ideal for circuit overload protection and energy management in transportation, industrial, and consumer electronics.
MULTICOMP PRO MC33177 PTC Resettable Fuse Specifications:
- Lead Material: Tin plated copper
- Soldering Characteristic: MIL-DTD-202, Method 208E
- Insulating Coating: Flame retardant epoxy
- Operating Current: 100mA to 3.75A
- Max Voltage: Up to 90V
- Temperature Range: -40°C to 85°C
- Dimensions: 12.7mm diameter, leads size 24AWG to 20AWG
- Rated Power: Up to 0.56W depending on current
- Trip Current: 150mA to 3.75A range based on part number
- Max Series Resistance: 0.08Ω at 23°C
- Agency Recognition: UL File E345437
- RoHS Compliant: Yes
Buy the Buy multicomp PTC Resettable Fuse Part Number MC33177 Online
Secure your electronic projects with the multicomp PTC resettable fuse MC33177, offering dependable overcurrent protection up to 90V. Designed for high reliability with low hold current and quick trip response, it features a compact radial leaded design with tin-plated copper leads that are solderable according to MIL-DTD-202 standards. Suitable for telecom, industrial, and consumer electronics, it complies with RoHS and UL safety standards. Order online now and enhance your circuit safety with this robust, easy-to-install fuse.
Order your multicomp Series MC33177 radial leaded PTC fuse today and ensure reliable overcurrent protection for electronic circuits and devices.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC33177?
You can click on the BUY or RFQ button to purchase MC33177 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC33177?
You can download the MC33177 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC33177?
MULTICOMP PRO
