MULTICOMP PRO MC34487 Wire-to-Board Crimp Housing
The MC34487 is a 6-way, single-row wire-to-board crimp housing made from beige nylon 66 with tin-plated brass contacts. It features a rated current of 3A (AC/DC), a minimum insulation resistance of 1000MΩ, and a rated voltage of 250VAC/DC. The operating temperature range is from -40°C to +105°C. Suitable for industrial applications, this connector is part of the Multicomp Pro product line, which is rated 4.6 out of 5 stars and comes with a 12-month limited warranty. Please note that these connectors do not include crimp contacts; contacts must be purchased separately.
MULTICOMP PRO MC34487 Wire-to-Board Crimp Housing Specifications:
- Material: Nylon 66
- Contact Material: Brass
- Finish: Tin Plated
- Current Rating: 3A (AC/DC)
- Voltage Rating: 250V AC/DC
- Insulation Resistance: 1000MΩ
- Maximum Contact Resistance: 20mΩ
- Operating Temperature Range: -40°C to +105°C
- Dimension A: 5.6 mm
- Dimension B: 2 mm
- Application: Wire to board connections
- Number of Ways: 6
- Connector Type: Crimp housing
- Standards: RoHS compliant
Buy the Multicomp 34487 U+2013 Reliable Wire-to-Board Crimp Housing for Industrial Applications
Purchase the Multicomp 34487 wire-to-board crimp housing online today to secure a durable, high-performance connection component suitable for industrial applications. Featuring a beige nylon 66 insulator and tin-plated brass contacts, this connector supports 3A current and 250VAC/DC voltage ratings. It operates effectively within a temperature range of -40°C to +105°C, ensuring safety and reliability. Ideal for wiring projects, this product offers quick installation, compliance with RoHS standards, and is backed by a 12-month warranty. Order now for dependable and efficient connections.
Order your Multicomp 34487 wire-to-board crimp housing today and ensure reliable, high-quality connections for your industrial wiring needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC34487?
You can click on the BUY or RFQ button to purchase MC34487 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC34487?
You can download the MC34487 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC34487?
MULTICOMP PRO
