MULTICOMP PRO MCAX40V108M16X32 Aluminium Electrolytic Capacitor
The multicomp pro aluminium electrolytic capacitor offers excellent performance with a wide operating temperature range from -40°C to +105°C, and voltage ratings from 6.3V to 450V DC. Featuring a capacitance range from 0.1pF to 15000μF, it provides reliable capacitance and low leakage current, suitable for power supply filtering and decoupling applications. Its compact design includes various case sizes, ensuring easy integration into diverse electronic circuits. Perfect for industrial, consumer, and automotive electronics requiring high capacitance in a small footprint.
MULTICOMP PRO MCAX40V108M16X32 Aluminium Electrolytic Capacitor Specifications:
- Operating Temperature Range: -40°C to +105°C
- Rated Working Voltage Range: 6.3V DC to 450V DC
- Capacitance Range: 0.1pF to 15000μF
- Capacitance Tolerance: +20% (at +20°C, 120Hz)
- Leakage Current: ≤ 3μA or 0.01CV, whichever is greater after 3 minutes
- Dissipation Factor (Tan 5): ≤ 0.07 at 120Hz, +20°C for smaller capacitance; increases by 0.02 for each additional 1000μF over 1000μF
- Maximum Permissible Ripple: 470-3300mA at 105°C, 120Hz depending on voltage
- Dimensions: Vary by case size, typical length ranges from 6mm to 36mm
- Mounting Type: Through-hole or surface mounting options
- Compliance: RoHS compliant, environmentally friendly
- Durability: Meets post-test leakage, capacitance, and dissipation factor limits after high temperature loading and shelf life conditions
Buy the Multicomp Series Aluminium Electrolytic Capacitor: MCAX40V108M16X32
Enhance your electronic projects with the high-quality multicomp aluminium electrolytic capacitor MCAX40V108M16X32, designed for stability and long life in demanding applications. With a voltage rating of 160V DC and capacitance of 100μF, this capacitor ensures reliable performance across a broad temperature range from -40°C to +105°C. Its compact size and robust construction make it ideal for industrial, automotive, and consumer electronics. Purchase online today and benefit from fast delivery, excellent support, and competitive pricing.
Buy Multicomp Series aluminium electrolytic capacitor MCAX40V108M16X32 now and experience unmatched reliability and performance for power filtering and decoupling needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCAX40V108M16X32?
You can click on the BUY or RFQ button to purchase MCAX40V108M16X32 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCAX40V108M16X32?
You can download the MCAX40V108M16X32 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCAX40V108M16X32?
MULTICOMP PRO
