MULTICOMP PRO MCBF7330330MU SMD Power Inductor
This high-quality surface-mount inductor offers a 33 picohenry inductance with a tolerance of 20%, designed for circuit filtering, energy storage, and switching power supplies. It features a maximum DC resistance of 0.066 ohms, a rated current of 3A, and operates efficiently within a temperature range of -55°C to +130°C. The inductor has a compact design with dimensions of 18.54mm by 15.24mm by 7.11mm, utilizing RoHS-compliant materials, including a T2 core, and features a 22-pin SMD case style for easy PCB mounting.
MULTICOMP PRO MCBF7330330MU SMD Power Inductor Specifications:
- Inductance: 33pH
- Inductance Tolerance: 20%
- DC Resistance Max: 0.066Ω
- DC Current Rating: 3A
- Self Resonant Frequency: 10MHz
- Inductor Case Style: SMD
- Number of Pins: 22
- Lead Spacing: 12.92mm
- External Depth: 7.11mm
- External Length/Height: 15.24mm
- External Width: 18.54mm
- Series: MCB
- Operating Temperature: -55°C to +130°C
- Material: T2 core, RoHS-compliant materials
- Wire: 0.45mm diameter, 155°C rated
- Solder: Lead-free (Sn99.3%/Cu0.7%)
- Core: T2 DR12.7 x 5.6C B5.8 F3.3
- Suitable for: Circuit filtering, energy storage, switching power supplies
Buy the Buy Multicomp Inductor Part Number MCBF7330-330MU Online
Purchase the Multicomp inductor efficiently online, designed for reliable power regulation, filtering in electronic circuits, and energy storage applications. The 33pH inductor features a 20% tolerance, a maximum DC resistance of 0.066 ohms, and a 3A current rating, ensuring high performance and durability. Its compact SMD case style with 22 pins and RoHS compliance makes it ideal for densely packed circuit boards. Buy now for seamless integration into your power supply and electronic projects.
Get Multicomp MCBF7330-330MU today—built for precision and long-lasting durability in high-current power applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCBF7330330MU?
You can click on the BUY or RFQ button to purchase MCBF7330330MU from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCBF7330330MU?
You can download the MCBF7330330MU datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCBF7330330MU?
MULTICOMP PRO
