MULTICOMP-PRO MCHVS1D12G Pin Header
This double row, vertical SMD pin header with cap features a 1mm pitch, 2-row configuration, and a height of 3.7mm. Made from high-temperature plastic with gold-plated copper alloy contacts, it offers reliable performance with a current rating of 1A and a voltage rating of 50V. Designed for surface-mount technology, it ensures low contact resistance of 20mΩ and insulation resistance of 1000MΩ. Suitable for compact electronics, it withstands 500V for one minute and operates effectively within -25°C to +105°C, making it ideal for various industrial applications.
MULTICOMP-PRO MCHVS1D12G Pin Header Specifications:
- Pitch: 1mm
- Number of Positions: 12
- Row: Double, 2 Row
- Height: 3.7mm
- Material: High-temp plastic (LCP UL94V-0)
- Contacts: Copper Alloy, Gold Plated
- Current Rating: 1A
- Voltage Rating: 50V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 500V for one minute
- Operating Temperature Range: -25°C to +105°C
- Color: Black
- Dimensions: Millimetres
Buy the Multicomp Series Vertical Pin Header: MC-HVS1-D12-G
Purchase the Multicomp Series MC-HVS1-D12-G pin header online now to ensure high-quality, reliable connections for your electronic projects. This vertical 2-row SMD header features a 1mm pitch, 3.7mm height, and is made from high-temperature plastic with gold-plated copper contacts. Designed for durability, it offers a 1A current rating, 50V voltage capacity, and withstands 500V for one minute. Ideal for compact and industrial electronics, it ensures low contact resistance and operates effectively within -25°C to +105°C, providing secure and efficient connections.
Get Multicomp Series MC-HVS1-D12-G today—built for reliable surface-mount connections and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCHVS1D12G?
You can click on the BUY or RFQ button to purchase MCHVS1D12G from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCHVS1D12G?
You can download the MCHVS1D12G datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCHVS1D12G?
MULTICOMP-PRO
