MULTICOMP PRO MCL034RHC Super Bright Red LED
The 3mm Round Super Bright LED Lamp in vibrant red emits at 660nm with a viewing angle of 36 degrees, ideal for indicator and display applications. Made from AllnGaP dice material, it exhibits a luminous intensity of up to 5000 med at 20mA, with a forward voltage of approximately 2.2V. Designed to operate within -40°C to +85°C, it features water-clear lens, a peak wavelength of 660nm, and has maximum ratings of 5V reverse voltage and 10μA reverse current, ensuring reliable performance in various electronic projects and devices.
MULTICOMP PRO MCL034RHC Super Bright Red LED Specifications:
- Dice Material: AllnGaP
- Peak Wave Length: 660nm
- Emitted Colour: Ultra Red
- Viewing Angle: 36 degrees
- Lens Colour: Water Clear
- IV (Luminous Intensity): up to 5000 med at 20mA
- Forward Voltage: 2.2V typical at 20mA
- Power Dissipation: up to 85 mW
- Operating Temperature Range: -40°C to +85°C
- Reverse Voltage: 5 V
- Reverse Current: 10μA at VR=5V
- Lead Soldering Temperature: 260°C for 5 seconds
- Dimensions: 3mm diameter, tolerance +0.25mm
- Peak Emission Wavelength: 660nm
- Spectral Line Half-Width: 20 nm
Buy the Multicomp Series 3mm Super Bright Red LED Lamp: MCL034RHC
Enhance your electronic devices with this high-performance 3mm super bright red LED. It offers a wavelength of 660nm, a wide viewing angle of 36 degrees, and luminous intensity up to 5000 med at 20mA. Perfect for indicators, displays, and signaling applications, operating reliably from -40°C to +85°C. Its water-clear lens enhances brightness, while easy soldering and compact size facilitate integration into various systems. Order online for fast delivery and superior quality assurance.
Buy Multicomp Series 3mm Super Bright Red LED Lamp now and experience unmatched reliability and performance in your electronic projects.
