MULTICOMP-PRO MCL059PURGW Multi-color LED lamp
This 5mm multi-color LED lamp features high brightness red and green emissions with peak wavelengths of 660nm and 568nm, respectively. Designed with AlGaAs/GaP dice material, it offers a wide viewing angle of 245°, luminous intensities up to 25mcd, and a forward voltage of 1.6 to 2.6V at 20mA. Operating within a temperature range of -40°C to +85°C, it's RoHS compliant and suitable for various electronic indicator applications, providing bright, reliable illumination with consistent color and visibility under different conditions.
MULTICOMP-PRO MCL059PURGW Multi-color LED lamp Specifications:
- Dice Material: AlGaAs/GaP
- Emitted Colour: Super Red/Green
- Lens Colour: White Diffused
- Peak Wavelength: 660/568nm
- Viewing Angle: 245°
- Luminous Intensity (IV): 50/15mcd
- Reverse Voltage: 5V
- Reverse Current: 10µA (VR = 5V)
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -40°C to +100°C
- Lead Soldering Temperature Range: 260°C for 5 Seconds at 2.4mm from body
- Forward Voltage (VE): 1.6/1.7V to 2.6/2.6V at IF = 20mA
- Peak Forward Current (IF Peak): 100mA (duty 1/10 at 1kHz)
- Recommended Operating Current: 20mA
- RoHS Compliant
Buy the Buy Multicomp LED Lamp Part Number MCL059PURGW Online
Enhance your electronic projects with this high-quality 5mm multi-color LED lamp offering bright red and green emissions. Featuring a wide viewing angle of 245° and luminous intensities up to 25mcd, it ensures high visibility in various applications. Compatible with standard soldering techniques, its operating temperature range from -40°C to +85°C makes it suitable for diverse environments. Buy online now to receive a durable, RoHS-compliant indicator that provides reliable, vibrant lighting for your electronic displays, signage, or control panels.
Get Multicomp LED Lamp MCL059PURGW today—bright red and green indicator illumination with wide viewing angle and reliable performance.
