MULTICOMP PRO MCMR50V106M5X7 Electrolytic Capacitor
This high-performance electrolytic capacitor features a short body length of 7mm, ideal for small, thin electronic devices. Suitable for high-density equipment such as office machines, calculators, car stereos, and mini-audio sets, it operates within a temperature range of -40°C to +85°C and has a rated voltage from 6.3V to 63V. The capacitor exhibits low leakage current, excellent stability at varied temperatures, and withstands circuit cleaning in solvents like Freon or steam, ensuring durability in compact electronic applications.
MULTICOMP PRO MCMR50V106M5X7 Electrolytic Capacitor Specifications:
- Operating temperature range: -40°C to +85°C
- Rated working voltage: 6.3V to 63V de
- Nominal capacitance range: 0.1 to 470nF
- Capacitance tolerance: ±20%
- Leakage current: 0.01CV or 3μA after 2 minutes
- Dissipation factor (tan δ) at 120Hz: 0.24 max for 6.3V, decreasing with voltage
- Maximum tan δ at 120Hz: 0.08 for 63V
- High and low temperature stability: -25°C/+20°C and -40°C/+20°C
- Post high-temperature load test at +85°C for 1000 hours: leakage current within original limits
- Shelf life: same limits after 500 hours at +85°C without voltage
- Body length: 7mm, diameter varies depending on capacitance and voltage
- Can withstand circuit-board cleaning with solvents or steam for 5 minutes
Buy the Buy Electrolytic Capacitor Part Number MCMR50V106M5X7 Online
Purchase the Premier Farnell electrolytic capacitor MCMR50V106M5X7 online today and benefit from its compact size, wide temperature range, and high stability. Perfect for small, thin electronic devices, it offers excellent leakage current performance and withstands circuit cleaning processes. Designed for high-density applications such as office machines, calculators, and car stereos, this capacitor provides reliable operation with a rated voltage of 10V and capacitance of 10μF, ensuring durability, efficiency, and easy installation in your electronic projects.
Buy Premier Farnell electrolytic capacitor MCMR50V106M5X7 now and ensure reliable performance in your small, high-density electronic circuits.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCMR50V106M5X7?
You can click on the BUY or RFQ button to purchase MCMR50V106M5X7 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCMR50V106M5X7?
You can download the MCMR50V106M5X7 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCMR50V106M5X7?
MULTICOMP PRO
